TIF035-05 Thermal Gel
- Bond Line Thickness (mm)
- 0.10 mm
- Density (g/cm³)
- 3.25
- Dielectric Strength (V/mm)
- ≥4000
- Flame Rating
- V-0
- Thermal Conductivity (W/m·K)
- 3.5
- Color
- Blue
TIF035-05 — Product overview
TIF®035-05 is a soft silicone gel-based gap filler pad, formulated with a special blend of fillers to provide both excellent thermal conductivity and superior softness. Compared to conventional thermal greases, TIF®035-05 has a higher viscosity, which effectively prevents filler separation from the silicone matrix and reduces filler migration, helping maintain consistent thermal performance. It is applied in a similar manner to thermal grease and is suitable for commercial dispensing or automated equipment. Typical applications include flip-chip microprocessors, PPGAs, micro BGA packages, BGA packages, DSP chips, circular silicon chips, LED lighting, and other high-power electronic components.
TIF035-05 — Features
Thermal conductivity
Soft, very low compression
Low thermal impedance
Operate automatically
Proven long-term reliability
Where this grade is used
Typical application targets for this grade include Heat-sink & frame, LED backlight module, LED lighting, High speed hardware driver, Micro heat pipe, Vihicel enginee controller, Telecom industry, Semiconductor automatic laboratory equipment.
Servers · GPU · accelerators · DIMM
Data Center & AI Servers
High-flux silicon and dense PCBs — CPU/GPU bond-lines, VRM/DIMM/NIC interfaces, and accelerator cold-plate paths. Match grade against clamp force, TIM impedance, and rework cadence.
EV packs · OBC · inverters · BMS
New energy
EV battery modules, traction inverters, on-board chargers, and renewable power conversion — thermal management for high-current cycling loads with HV isolation requirements.
Drives · IGBT · controllers · sensors
Power Tools & Control Systems
Industrial controls, motor drives, power-stage IGBTs, and rugged modules — thermal interfaces, sealing, and encapsulation built for serviceable assemblies and harsh environments.
TIF035-05 — datasheet specifications
Values below are transcribed from the official datasheet (PDF: TIF035-05-Data-Sheet.pdf). Use the linked PDF for sign-off and lot-specific CoA.
Request application engineering support| Parameter | Value (typical / as stated) | Method / note |
|---|---|---|
| Color | Blue | Visual |
| Construction & Composition | Ceramic filled silicon material | — |
| Flow Rate (g/min) | 30 | Ziitek Test Method (30 cc syringe / 2.5 mm orifice / 90 psi) |
| Density (g/cm³) | 3.25 | ASTM D297 |
| Thermal Conductivity (W/m·K) | 3.5 | ASTM D5470 |
| Thermal Impedance @10psi (°C·in²/W) | 0.080 | ASTM D5470 |
| Thermal Impedance @50psi (°C·in²/W) | 0.075 | ASTM D5470 |
| Recommended Operating Temp (°C) | -45~200 | Ziitek Test Method |
| Dielectric Strength (V/mm) | ≥4000 | ASTM D149 |
| Bond Line Thickness (mm) | 0.10 | Ziitek Test Method |
| Flame Rating | V-0 | UL94 |
| Shelf Life (months) | 12 | — |
* Match values to the PDF revision cited on your purchase order.
Related thermal putty and thermal gel models
TIF035-05 — common questions
Replacing another vendor’s TIM or need a stack review? Send drawings — applications responds quickly.
Talk to an engineerWhat is the nominal thermal conductivity of TIF035-05?
The customer workbook lists nominal through-plane conductivity as 3.5 W/m·K. What you measure depends on pressure, gap, and fixture — use the technical documentation as the reference.
Can Ziitek supply TIF035-05 die-cut or in custom thickness?
Yes — send DXF/DWG outlines and stack height. Thermal putty and thermal gel parts are routinely converted at Ziitek; tolerances depend on thickness and geometry.
Where is the documentation for TIF035-05?
Download the technical documentation from this page when available. If your revision differs, name the file from your RFQ so applications engineering matches it.
Is TIF035-05 RoHS-aligned?
Ziitek targets RoHS-oriented formulations across TIM lines. Cite the compliance block for audits and tell us if you need additional regional substance lists.
