TIG7835L Thermal Grease
- Density (g/cm³)
- 6.5
- Recommended Operating Tem…
- -40 ~ 250
- Resistivity (Ω·m)
- <1×10⁻⁴
- Thermal Conductivity (W/m·K)
- 35
- Viscosity (mPa·s)
- <10
- Color
- Silvery white
TIG7835L — Product overview
TIG®7835L is a gallium-alloy liquid-metal thermal interface compound that achieves a liquid state and low surface tension at room temperature through advanced alloying, without requiring heating to a separate melting point. It combines high fluidity with very high thermal conductivity (35 W/m·K) and is resistant to evaporation and leakage, with stable physical and chemical properties for long-term operation. As an underlying technology for high-power heat dissipation, TIG®7835L is well suited to demanding cooling needs that exceed the capability of traditional silicone grease. Note that the alloy is electrically conductive (resistivity <10⁻⁴ Ω·m) and can short-circuit adjacent traces or pads if it spreads, and it corrodes aluminum on direct contact, so installation must contain the metal within the bond line.
TIG7835L — Features
Very high thermal conductivity of 35 W/m·K
Liquid at room temperature with high fluidity and low surface tension
Excellent long-term stability with low evaporation
Thoroughly fills contact surfaces to create very low thermal resistance
Wide operating range of -40 to 250 °C
Non-toxic and RoHS compliant
Where this grade is used
Typical application targets for this grade include High-end microprocessors and CPUs, AI chips, Graphics processing chips, Set-top boxes, LED TVs and LED lighting fixtures, Notebook thermal interfaces, Liquid-cooled heat-dissipation assemblies.
Servers · GPU · accelerators · DIMM
Data Center & AI Servers
High-flux silicon and dense PCBs — CPU/GPU bond-lines, VRM/DIMM/NIC interfaces, and accelerator cold-plate paths. Match grade against clamp force, TIM impedance, and rework cadence.
Drives · IGBT · controllers · sensors
Power Tools & Control Systems
Industrial controls, motor drives, power-stage IGBTs, and rugged modules — thermal interfaces, sealing, and encapsulation built for serviceable assemblies and harsh environments.
TIG7835L — datasheet specifications
Values below are transcribed from the official datasheet (PDF: TIG7835L.Data-sheet.pdf). Use the linked PDF for sign-off and lot-specific CoA.
Request application engineering support| Parameter | Value (typical / as stated) | Method / note |
|---|---|---|
| Color | Silvery white | Visual |
| Form | Liquid | Visual |
| Construction & Composition | Gallium alloy | — |
| Density (g/cm³) | 6.5 | ASTM D792 @25°C |
| Thermal Conductivity (W/m·K) | 35 | ISO 22007 @25°C |
| Specific Heat Capacity (J/g·°C) | 0.39 | ASTM E1269 @25°C |
| Resistivity (Ω·m) | <1×10⁻⁴ | ASTM D257 |
| Viscosity (mPa·s) | <10 | GB/T 10247 |
| Melting Range (°C) | >9 | ASTM D3418 |
| Solidification Range (°C) | <-28 | ASTM D3418 |
| Recommended Operating Temperature (°C) | -40 ~ 250 | — |
* Match values to the PDF revision cited on your purchase order.
Related thermal grease models
TIG7835L — common questions
Replacing another vendor’s TIM or need a stack review? Send drawings — applications responds quickly.
Talk to an engineerWhat is the nominal thermal conductivity of TIG7835L?
The customer workbook lists nominal through-plane conductivity as 35 W/m·K. What you measure depends on pressure, gap, and fixture — use the technical documentation as the reference.
Can Ziitek supply TIG7835L die-cut or in custom thickness?
Yes — send DXF/DWG outlines and stack height. Thermal grease parts are routinely converted at Ziitek; tolerances depend on thickness and geometry.
Where is the documentation for TIG7835L?
Download the technical documentation from this page when available. If your revision differs, name the file from your RFQ so applications engineering matches it.
Is TIG7835L RoHS-aligned?
Ziitek targets RoHS-oriented formulations across TIM lines. Cite the compliance block for audits and tell us if you need additional regional substance lists.
